| Technical Specifications |
| Model No. |
IPC-QDFR8MP-TD-AI-S |
| Camera |
| Image sensor |
1/2.5″ Progressive CMOS |
| Min. illumination |
Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON |
| Shutter time |
1/3s ~ 1/10,000s |
| Lens |
2.8mm @F2.0 Angle of view: 109° |
| Lens mount |
M12 |
| Day & night |
IR cut filter with auto switch |
| Digital noise reduction |
3D DNR |
| Wide dynamic range |
TRUE WDR |
| Compression Standard |
| Video compression |
H.264 / MJPEG / H.264+/H.265+ |
| H.264 codec profile |
Main profile |
| Bit rate |
32 Kbps ~ 16 Mbps |
| Dual streams |
Support |
| Image |
| Max. Image Resolution |
8MP 3840(H)×2160(V) |
| Frame rate |
60Hz:(1~15fps@4K, default 15fps@4K 8MP (3840×2160),5MP(3072*1728)(2592*1944),4MP(2592×1520),3MP(2304×1296), 1080P(1920×1080), 720P(1280×720), |
| Image settings |
Rotate Mode, Saturation, Brightness, Contrast Sharpness adjustable by client software or web browse |
| BLC |
Yes, zone configurable |
| ROI Codec |
Support |
| Network |
| Network storage |
NAS (Support NFS,SMB/CIFS), ANR |
| Alarm trigger |
Motion detection, tampering alarm, network disconnect, IP address conflict, storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Interoperability |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Security |
User Authentication, watermark |
| Interface |
| Communication interface |
1 RJ45 10 M / 100 M Ethernet interface |
| Web Browser |
IE 7, IE 8, IE 9 |
| P2P Connection |
Built in |
| Microphone |
Built in |
| Mobile App |
RXCAMVIEW Android/iPhone |
| General |
| Operating conditions |
(-22°F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power supply |
12 VDC ± 10% , PoE (802.3af) |
| Power consumption |
Max. 5W (Max 7W with IR cut filter on) |
| Weatherproof rating |
IP66 |
| IR range |
Up to 100 ft |
| Dimension |
4.33″ x 3.88″ x 4.33″ |
| Weight |
1.1 lbs |
