| Technical Specifications |
| Model No. |
LHDVR0804-4K |
| Video/Audio input |
| Video compression |
H.264,H.264+, H.265, H.265+ |
| Video input |
8-ch Analog, 4-ch IP or 12-ch IP |
| Video input interface |
BNC (1.0 Vp-p, 75 Ω) |
| Supported Camera Types |
8MP/5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF |
| Audio compression |
G.711u |
| Audio input |
8-ch |
| Audio input interface |
RCA (2.0 Vp-p, 1 kΩ) |
| Video /Audio output |
| HDMI output |
1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 ×1440)/60Hz, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60Hz, 1024 ×768/60 Hz |
| VGA output |
1-ch, resolution: 1920×1080P / 60Hz, 1280×1024 / 60Hz, 1280×720 / 60Hz, 1024×768 / 60Hz |
| CVBS Output |
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704×576,NTSC:704×480 |
| Recording resolution |
4K Model: Analog : 8MP（15fps） 5MP（20fps） 4MP/3MP/1080P/720P/960H （30fps） IP : 8MP/5MP/3MP1080P/720P |
| Frame rate |
Main stream:25fps(p)/30fps(N) Sub-sream:WD1/4CIF@12fps(non-real-time);CIF/QVGA/QCIF(real-time) |
| Video bit rate |
32 Kbps-10 Mbps |
| Audio output |
8-ch, RCA (Linear, 1 kΩ) |
| Audio bit rate |
64 Kbps |
| Dual-stream |
Support |
| Stream type |
Video, Video & Audio |
| Synchronous playback |
8-ch |
| Playback Resolution |
8MP/5MP/3MP/1080P/720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Network Management |
| Remote Connections |
128 |
| Network Protocols |
TCP/IP, PPPoE, DHCP, Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,ONVIF |
| Hard Disk |
| SATA |
2 SATA interface |
| Capacity |
Up to 24TB capacity |
| External interface |
| Network interface |
1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| Serial interface |
1; standard RS-485 serial interface, half-duplex |
| USB interface |
1x USB2.0, 1x USB3.0 |
| General |
| Power supply |
12V DC |
| Consumption |
≤ 20 W |
| Working temperature |
-10 ºC ~+55 ºC (14 ºF ~ 131 ºF) |
| Working humidity |
10% ~ 90% |
| Chassis |
1U chassis |
| Dimensions |
15 x 12 1/2 x 2 |
| Weight |
≤ 1.5Kg (3.3lb) |
