| Technical Specifications |
| Model No. |
NVR-6116 |
| Video/Audio input |
| Video compression |
H.264, H264+, H265, H265+ |
| IP Video input |
8-ch |
| Incoming Bandwidth |
112 Mbps |
| Outgoing Bandwidth |
96 Mbps |
| Two-way audio input |
N/A |
| Video /Audio output |
| HDMI output |
1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID） |
| VGA output |
1-ch, resolution: 1920 x 1080P /60 Hz ,1440 x 900 /60 Hz, 1280 x 1024 /60 Hz,1280 x 720 /60 Hz, 1024 x 768 /60 Hz |
| CVBS output |
N/A |
| Video spot output |
N/A |
| Encoding resolution |
4K/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF |
| Frame rate |
30 fps |
| Video bit rate |
32 Kbps ~ 8192 Kbps, or user defined (Max. 8192 Kbps) |
| Audio output |
N/A |
| Audio bit rate |
N/A |
| Dual-stream |
Support | (Sub-stream at CIF / QCIF: 30fps) |
| Stream type |
Video, Video & Audio |
| Playback resolution |
5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF |
| Synchronous playback |
8-ch 1080P |
| Hard Disk |
| SATA |
2 SATA interfaces |
| Capacity |
Up to 24TB capacity for each disk |
| Interface |
| Network interface |
1 RJ-45 10 / 100 / 1000 Mbps self-adaptive Ethernet interface 8 independent 10 / 100 Mbps PoE Ethernet interfaces |
| Web Browser |
IE 7, IE 8, IE 9 |
| P2P Connection |
Built in |
| Mobile App |
RXCAMVIEW Android/iPhone |
| Serial interface |
N/A |
| USB interface |
2 x USB2.0 |
| Reset |
Press 10 Sec Reset |
| General |
| Power supply |
12V DC |
| Consumption |
≤15 W |
| Working temperature |
14ᵒF – 131ᵒF |
| Working humidity |
10% ~ 90% |
| Chassis |
1U chassis |
| Dimensions |
12x9x2 inch |
| Weight |
< 2.2 Lb |
