| Model No. |
IPC-PTZ-E25XIR2MP-C |
| Camera |
|
|
|
|
|
| Image sensor |
1/2.8″ Progressive CMOS |
| Image Resolution |
1920×1080 |
| Signal System |
PAL/NTSC |
| Min Illumination |
Color: 0.002 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| White Balance |
Auto/Manual/ATW/Indoor/Outdoor |
| AGC |
Auto/Manual |
| S/N Ratio |
> 50 db |
|
|
|
|
| 3D DNR |
Support |
|
|
|
|
| DWDR |
Support |
|
|
|
|
| EIS |
Support |
|
|
|
|
| Backlight Compensation |
Support |
| Shutter Speed |
NTSC: 1-1/10,000s |
|
|
|
| Day & Night |
Full Color Day & Night |
|
|
| Optical Zoom |
25X |
|
|
|
|
| FOV |
Horizontal field of view: 56.9° to 2.9° (wide-tele), |
|
|
|
|
| Vertical field of view: 32.2° to 1.6° (wide-tele), |
|
|
|
|
| Diagonal field of view:65.2° to 3.3° (wide-tele) |
|
|
|
|
| Privacy Mask |
8 Privacy Mask, Max 8 Zones can be masked simultaneously |
| Focus Model |
Auto/Manual |
| Lens |
|
|
|
|
|
| Focal Length |
4.7-125MM |
| Zoom Speed |
Approx. 3s |
| Min Working Distance |
10mm(W)-1000mm(T) |
| Pan and Tilt |
|
|
|
|
|
| Pan Range |
360°Endless |
| Pan Speed |
Pan speed: configurable from 0.6° to 80°/s; preset speed: 120°/s |
|
|
|
|
| Tilt Range |
0°- 90°(Auto Flip) |
|
|
|
| Tilt Speed |
Tilt speed: configurable from 0.6° to 80°/s, preset speed 100°/s |
|
|
|
|
| Number of Preset Position |
256 |
| Patrol |
8 Patrols, Up to 32 Presets per patrol256 |
| Pattern |
4 Patterns, with total recording time no less than 10 mins |
| Power-off Memory |
Support |
| Park Action |
Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Random Scan |
| PTZ Position Display |
On/Off |
| Color Mode |
|
|
|
|
|
| Warm Light |
8 LEDs |
| Light Distance |
300 Ft |
| Light Intensity |
Auto adjusted |
| Network |
|
|
|
|
|
| Onvif |
Support |
| Protocols |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, |
| Dual Streams |
Support |
|
|
|
|
| Security |
User Authentication, Host Authentication |
|
|
| Interface |
|
|
|
|
|
| Communication interface |
1 RJ45 10 M / 100 M Ethernet interface |
| User/Host level |
Up to 32 users，3 Levels: Administrator, Camera control, Live view only |
| Web Browser |
IE 7, IE 8, IE 9 |
| Camera Control |
Pan / Tilt, Zoom, Focus, Click centering, Drag zoom, Iris, Preset position call |
| Protocols |
Self-adaptive |
| General |
|
|
|
|
|
| Menu Language |
English |
| Power |
DC 12V/POE+, max. 22 W |
| Working Temperature |
-20°C-60°C，≤90%RH(frostless) |
| Mounting |
Wall Mount Included |
| Weather proof rating |
IP66, TVS 3,000V lightning protection, surge and voltage protection |
| Dimensions |
Ø 160 mm × 270 mm (Ø 6.3″ × 10.6″) |
| Weight |
2.5 kg (5.51lb.) |
